X20 linear slim high power wash wall lamp is suitable for outdoor buildings,bridges ancient architecture pan light projection lighting. The product is a vertical lighting,The vertial illumination is emphasizas for the effect of building space and enhance the customer for the embodiment of the space sense,The lamp structural is drainage design and the function is more stable performace;The projection distance 3 to 6 meters above;The angle adjustment 0~110°C ,It can realize the ON/OFF, dimming, RGB. The applicable environment temperature is 35 °C~55°C. The lamp life time and lanterns is equal to more than 35000 hours.
Material :the lamp body is 6063 tensile aluminum alloy;The side cover is 6063 die casting aluminum .The len is PMMA,The surface glass is 3mm tempered glass is 3mm
tempered glass ; The installation bracket is 6063 aluminum alloy;The transparent surface is weathering glue waterproof PU waterproof potting glue and The
improted stainless steel screw.
Surface Treatment : ALL external lighting componets and parts of the holder -Mechanical and chenmical anti-corrosion treatment,Akesu,Nobel ultraviolet
resistant polyester powder and outdoor grade spraying system or oxidation treatmentand conventional anti-uv5 years protection。
Electric Appliance: Built-in electronic drive with over temperature overload protection.
Installation :Outlet wire 0.15m;5 cores cable 2x1.0m㎡+3x0.3mm2rubber cable（DMX Dimming , RGB version)。
Outlet wire 0.15m ;2 cores cable wire 2x1.0mm2 (ON/OFF version )
Option :optionaldifferent beam angle .Optional other color surface coating.Customized other outlet wire length.
