M1 high brightness and high density led light is suitable for building facades and glass curtain wall facade etc. The productadopts the professional optical design and the light guide plate is imported from Japan mitsubishi glass fiber organic board ,the effects of light color is closed to the perfect;the light signal transmission adopts the double parallel control technology,so the performance is stable and reliable , the installation method is simple and anti-wind 10 levels of gales ,IT can realize ON/OFF,dimming ,RGB.the applicable temperature is -35 ℃ ~ +55 ℃.The amp life time is more than or equal to 35000 hours.
Material :the lamp body is 6063 tensile aluminum alloy;The side cover is 6063 aluminum alloy and PMMA lens ,The new light guide glass fiber organic board is imported from
Mitsubishi,Janpan .the mounting brackets is 6063 aluminum alloy。the transparent surface is weathering glue waterproof PU ,the screw is stainless steel screws 。
Surface Treatment : ALL external lighting componets and parts of the holder -Mechanical and chenmical anti-corrosion treatment,Akesu,Nobel ultraviolet
resistant polyester powder and outdoor grade spraying system or oxidation treatmentand conventional anti-uv5 years protection。
Electric Appliance: Built-in electronic drive with over temperature overload protection.
Installation :Outlet wire 0.15m;4cores cable 0.35m㎡and 2cores 0.75 mm2rubber cable（DMX Dimming , RGB version)。
Outlet wire 0.15m;2 cores cable 0.75 mm2(ON/OFF version )
Option :Optional one side lighting or double -side ligthing or the guide lighting plate width .
Optional other color surface coating.Customized other outlet wire length.
